Although perhaps now better known for ship repair rather than shipbuilding, Cammell Laird and the wider APCL group is now heavily engaged in building sections for the Dreadnought submarine and Type 26 Frigate programs. Here we look at how this organisation has assumed a vital role in supporting the fleet and become a key enabler in major naval projects.
Cammell Laird in Birkenhead joined forces with A&P Falmouth and A&P Tyne in 2023 to become APCL, the largest commercial ship repairer in the UK. APCL employs over 1,400 people, has 9 operational dry docks, 4 building berths, 3km of wet berths and has supported over 1,000 ships in the past 5 years. A strategy of pursuing both commercial and naval contracts has been successful, a diverse customer base helps ensure a reliable flow of work. Last year, specialist marine painting company Neway Industrial Services, based in the Birkenhead yard also became part of the APCL group.
Royal Fleet Auxiliary ships are maintained through the 10-year in-service support contracts by CL and A&P Falmouth This framework guarantees the yard continuity of work which in turn has supported investment and stability. CL has two cluster contracts – now responsible for the maintenance of the 4 Tide-class tankers, 2 Wave-class tankers, RFA Fort Victoria, RFA Proteus and RFA Stirling Castle. A&P Falmouth looks after the 3 Bay-class landing ships, RFA Argus, the Batch 1 OPVs and HMS Scott.
APCL can also provide support to RFA vessels overseas. In April they managed an assisted maintenance period for RFA Argus at the Larsen & Toubro Kattupalli shipyard in India which involved 150 work items. They also coordinated a self-maintenance period for RFA Lyme Bay, the first time RN/RFA maintenance has been conducted in an Indian shipyard.
The CL yard on Merseyside has a shipbuilding heritage that dates back to the 1800s, having built many major warships and submarines for the RN. The original business folded in 1993 after the completion of HMS Unicorn but was subsequently resurrected as a ship repair yard in 2007. Against the odds, the yard also returned to the shipbuilding business, fabricating flight deck units for the QEC aircraft carriers in 2010. Most new build projects have been small ferries but in 2015 CL won the prestigious contract to build the Antarctic support and research ship, RRS Sir David Attenborough.
The complexity of the SDA proved to be very challenging and CL took a substantial financial loss on the project with the ship eventually being sent to Denmark for defect rectification before it was accepted. Survival of the yard has been in doubt at times, but CL’s finances and order book have improved recently. In 2023-24, turnover increased to £146M, compared with £122M the previous year, while profits almost doubled to £6.8M.
CL workforce has also grown substantially, now numbering around 650. Adjacent to the shipyard is the Engineering College, a not-for-profit organisation, part of a national network that trains apprentices in STEM subjects. Around 100 employers send their apprentices to the college, which has around 45 staff. 200 of the 450 trainees at the college are CL apprentices who undergo a 4-year course learning welding, mechanical or electrical engineering while gradually being introduced to working in the yard. Applications to CL for apprenticeships are hugely over-subscribed as it offers a pathway to gain skills that are in great demand while being paid.
Dreadnought outer hull
The APCL group are responsible for fabricating most of the external sections for Dreadnought-class submarines that are outside the pressure hull and is the largest outsourcing partner to BAE Systems for submarine units. The subcontract includes the manufacture of casing, keel, waist and internal units. Parts for HMS Dreadnought and HMS Valiant (boats 1 and 2) are currently in production at Birkenhead and A&P Tyne.
APCL are in negotiations with BAE Systems and the Submarine Delivery Agency (SDA) for further batch (DP3) of Dreadnought work, potentially a 10-year work stream, which will likely see contracts placed for an additional 122 units to be built at Birkenhead and 22 on Tyneside. There will also be further investment at the Tyne West facility to support this fabrication work.
The top casing sections are being fabricated upside down in the construction halls in Birkenhead and are particularly impressive, indicating the huge size of these submarines. As CL warned the customer, they experienced considerable challenges with manufacturing these units as the design specifies thin steel to save top weight. To avoid distortion, some units have had to be reworked using low-temperature welding techniques, slightly impacting the delivery schedule. CL is also responsible for the preservation and coatings of these steel parts that will be submerged in seawater for many years. The completed sections are carried by barge up the coast to Barrow, where they will be consolidated with the pressure hulls in the Devonshire Dock Hall.
CL are also building a bespoke Buoyancy Assist Module (BAM) for Dreadnought. A BAM comprises large port and starboard floatation tanks, joined with overhead arches. The submarine is positioned between the tanks that are then temporarily attached to the vessel and pumped dry. The Dreadnought BAM is the first of its kind manufactured in the UK and will be used to reduce the submarines’ draft as they leave Barrow for the first time. Even with its own buoyancy tanks filled with air, Dreadnought will have such a deep draft that it would not be able to get over the dock sill system without being raised slightly. The heavy lead ballast is integral to the keel and cannot be added once the boat is in the water.
Type 26 blocks
APCL are also a key supplier to the Type 26 frigate programme. A&P Tyne built 4 stern units totalling 220 tonnes for HMS Belfast (ship 3) which were delivered to Govan last year. CL are currently working on further units for HMS Belfast as well an an 850-tonne lower block propulsion section for ship 4, HMS Birmingham. BAES have asked CL to take on increasingly complex projects that involves consolidating units into blocks and the addition of pipework and cabling into the sections. The lower block for HMS Birmingham will be transported by barge to Govan in the new year and will go into the new Janet Harvey shipbuilding hall to be consolidated into ship 4.
The steel plate used in these vessels comes mainly from Turkey and Spain as the UK no longer has the manufacturing capacity for this grade. (Discussion of this strategic folly is outside the scope of this article.) CL has an off-site plasma-cutting facility that prepares thousands of parts that vary enormously in size. These components are supplied to the yard for welding, each carrying a unique number that identifies where they will go. This work requires high standards and the welds are subject to tight quality control. Small numbers of welders from the Philippines have been employed by the company to address the shortages in this trade. The use of foreign labour is always controversial but the Philippino staff are well-liked and respected for a great work ethic.
With the Dreadnought and Type 26 production in full swing, BAE Systems is now operating at maximum capacity, offering opportunities for APCL and other UK yards, such as Ferguson Glasgow, to take on additional work to support these programmes. Should Norway choose to buy Type 26 frigates built in the UK, this will demand even greater fabrication work and opportunities for the supply chain.
By subcontracting, BAES can alleviate its capacity issues and spread the economic benefits of major naval programmes more widely across the UK, helping to support jobs and the up-skilling of a new generation of shipyard workers. With commercial, RFA and BAES contracts, CL is now in a solid position and is considering investment in new technologies, construction facilities and warehousing.
