NavyX sits within the RN’s Develop Directorate and is responsible for testing and trialling new technology with them aim of delivering new capabilities to the fleet faster than by traditional routes. Here we take an overview of NavyX’s work.
NavyX is officially described as the RN’s “Autonomy, Lethality and Innovation accelerator”. Inspired by the US Navy’s NavalX and established in 2019, it is a small team comprising 22 people drawn from the Civil Service, Navy and industry. 5 sailors are assigned as ship’s company for the Experimental Trials Vessel XV Patrick Blackett, 2 people serve at the Defence BattleLab in Dorset while the remaining 15 work on project planning and management.
Maritime Autonomy
The main focus for NavyX is the development of uncrewed and autonomous capabilities. There are other projects but currently, activity is centred on trials conducted on XV PTBK and development of the autonomous Pacific 24 RIB (APAC24).
Previously NaxyX conducted the RN’s first trials of the 13m Maritime Demonstrator For Operational eXperimentation, (MADFOX) Uncrewed Surface Vessel. This work was primarily to explore issues around USV safety, regulatory compliance, potential mission and payloads. The trials of MADFOX culminated in the launch of a Switchblade 300 Tactical Missile System (Loitering Munition) while controlled remotely from ashore during the REPMUS exercise in September 2021.
In parallel the Maritime Autonomous Platform Exploitation (MAPLE) information architecture has been developed by DSTL, used for mission planning and control for RN autonomous assets. These standardised data protocols will be foundational to having interoperable uncrewed systems in the future and should transition into the RN’s Naval Strike Network. It is also intended to be compatible with the US Navy’s Common Control System (CCS) and could become a NATO standard in future. MAPLE has also been trialled in specific scenarios such as anti-ship missile defence using recoverable decoys and harbour protection.
The remotely controlled or autonomous RIB has potential applications including anti-piracy operations, border control, persistent intelligence gathering, maritime security and force protection. Fitting within the existing footprint of standard ship’s boats, APAC24 could be deployed to conduct hazardous missions without risking sailors. Development of the APAC24 has been slow, first demonstrated in 2016, BAE Systems has a contract to build the boats with NavyX conducting evaluation. An integration demonstration was conducted with a Type 23 frigate (HMS Argyll) in 2021 as well as proving land-based control from Portsdown Technology Park. Land-based live-firing tests with the Seahawk Multi-Weapon Station fitted to the boat were carried out in May 2023. The next steps are to develop launch and recovery methods, prepare the boat for live-firing at sea and likely participation in the REPMUS 24 exercise in September.
-
Autonomous Pacific 24 RIB showing equipment fit. -
MADFOX was the RN’s first major venture into USV experimentation and was derived from the L3Harris Maritime Autonomy Surface Testbed (MAST). -
The Giraffe 1X is a small, 3D, active electronically scanned array (AESA) X-band radar and will be trialled by the RN soon (Photo: SAAB AB).
XV Programme
XV Patrick Blackett was acquired rapidly by UK defence procurement standards, the business case was approved in August 2021 and the ship had been formally named and accepted by July 2022. Unfortunately, she did little for the 7 subsequent months as the RN struggled with certifying a completely unfamiliar type of vessel.
In May 2023 she conducted an at-sea test of a prototype quantum sensor, developed by Imperial College, London. This technology could be developed into an inertial navigation system that is far more accurate over a longer period than current mechanical gyro and accelerometer-based INS. The containerised prototype was carried on the deck of PTBK and visited London, the concept proved viable, although it was discovered that passing under a steel bridge (the QE2 Dartford Crossing) created interference. This kind of insight can only be gained by real-world trials on a ship. Quantum navigation technology was tested further in Feb 2024 by embarking the system in a PODS container on board MoD-chartered vessel MV Hurst Point.
In June 2023, and again in November 2023, PTBK participated in trials to support the RN’s Navigation Radar Programme (NRP). Two radar terminals were placed in a PODS container with the aerials mounted on the top to replicate the height they would be on the Hunt-class minehunters. The Kelvin Hughes SharpEye-based radar series under test were the RT1084 currently installed on Type 23 frigates and the RT1083 system which will replace the RT1007 as the standard fleet navigation radar.
In August 2023, Damen Group which built the XV, delivered a digital twin model of the ship to the RN. NavyX will use the digital model to explore future technologies in a safe environment, before onboard testing. Using the Damen Triton remote monitoring and data collection system already installed on the ship, accurate and up-to-date engineering data can be compared with the predicted model.
-
XV Patrick Blackett alongside in Gosport with navigational radars under test mounted on the working deck (Photo: S. Wenham). -
Navy PODS loaded onto the XV in Portsmouth (Photo: S. Wenham). -
PTBK alongside at HMS President in London, with the Quantum Navigation prototype in a container on the working deck, May 2023.
The quantum accelerometer uses ultracold atoms and lasers to measure even the tiniest of the vessel’s motions. This can be used to as the basis of extremely accurate inertial navigation systems.
NavyX’s long-term goal is to demonstrate that PTBK can be operated fully autonomously. There are multiple steps in the process towards achieving this. Firstly the ship’s sensors need to be integrated with the MAPLE open computing environment and additional sensors may need to be added to the vessel. This must be certified, linked with the ship’s control systems and connected to the remote operating centre. The next step would be to reduce operators on the bridge while the ship is under remote control and complete day and night demonstration passages in various weather conditions.
The final goal of full autonomy is the hardest step because as a baseline requirement when uncrewed, the vessel must not be a hazard to other mariners and conform to International Regulations for Preventing Collisions at Sea (COLREGS). Once regulatory conditions are satisfied, the focus can then become developing use cases and combat capabilities for large USVs.
Taking advantage of the long-range of the PTBK, in September 2023, the XV sailed to Portugal to participate in the annual NATO REPMUS experimental exercise. While overseas, the ship hosted a variety of trials with UUVs, ASW capabilities, command-and-control equipment and SATCOM systems embarked while integrated into the RN’s nascent Naval Strike Network. NavyX expects to deploy PTBK to REPMUS again this September to continue development trials and possibly even operate the ship autonomously.
Other work being conducted by NavyX includes Above Water Battlespace data exploitation, development of Tactical Data Links and methods of at-sea communications in denied environments. 11 Saab Giraffe 1X radar sets were delivered to the MoD in June 2023, mainly for use by the Army but one set is due to be tested by the RN on board the XV. Being compact, the Giraffe X1 can be integrated into most platforms and is especially effective for UAS detection and warning.
Establishing an innovation team and procuring a dedicated trials platform has relieved the overstretched frontline fleet of some test and development duties, making for a more efficient use of resources. Whether NavyX has adequate resources and scale to deliver actual capabilities at the pace required is debatable but its multiple work streams will undoubtedly benefit the future fleet.
